This new colorPol® material is designed for use in the visible spectrum from 500 to 720 nm where is yields a transmittance of from 60% to 84%. Over the spectral range the extinction ratio is about 100,00:1. It is available in sizes up a maximum of 50 x 40 mm and is 280 microns thick. If needed, an optional wide band anti-reflection coating is available in the VIS 600 BC4 CW01 version. As with all colorPol® materials, this new one can be ordered in standard round sizes and just about any rectangle size up to it maximum size and can be included in the sample sets. High quality laminated versions with low wavefront distortion versions are also available.
Please contact us for more information.
