UV Fibers

What Is Important in UV?

Three criteria are crucial in deciding which fiber is suitable for which application:

1. Initial Attenuation
The attenuation of a new fiber prior to UV irradiation depends on the wavelength and is typically provided in dB/km.

2. Solarization
Solarization refers to attenuation caused by UV radiation. The greatest impairment occurs at wavelengths below 250 nm. The damage is particularly significant at about 214 nm. The magnitude of these additional losses strongly depends on the fiber type.

3. Stability after UV Irradiation
After irradiation, some of the initial solarization damage recedes after a few hours. The condition of the fiber after regeneration remains permanent.

FVP Fibers

Standard high-OH fibers for Vis transmission exhibit relatively low attenuation in the UV spectrum as well.

FVP UVM Fibers

Inexpensive standard UV fibers: The core of a high-OH fiber has been modified to exhibit improved properties under UV light.

FVP UVMI Fibers

In FVP UVM fibers that have been enriched with hydrogen and that exhibit optimal properties for UV light, the hydrogen enrichment is lost again after a short time. The lifetime can be extended considerably by cooling or by using a large core diameter.

FDP Fibers

Solarization-resistant fibers used in the deep UV (190 nm) do not have limitations in performance and lifetime, even without cooling.
