Energy Meter with Integrating Sphere

High-precision measurements at laser powers up to 1 kW.

IS50A-1KW-RMT joulemeters with integrated integrating sphere are tailor-made for your specific requirements. This allows you to carry out high-precision NIST traceable energy measurements at laser powers of up to 1 kW. A unique GENTEC-EO coating provides the detector of these water-cooled measuring devices with unsurpassed resistance so that it can withstand even high energies.

Individually calibrated energy meters for your application

This powerful IS50A-1KW-RMT joulemeter with integrated integrating sphere is designed for precise laser measurements on high-power lasers. With an aperture of 50 mm, it is suitable for laser powers up to 1 kW and repetition frequencies up to 1000 Hz. The calibration complies with the standards of the National Institute of Standards and Technology (NIST). The detector covers a spectral range from 0.19 to 2.5 µm and the measurement results are reproducible with an accuracy of ± 0.5 %.

A special coating developed by the manufacturer allows the detector to withstand a maximum energy density of 400 mJ/cm². Even with intensive use, the IS50A-1KW-RMT joule meters are reliable and durable. Each unit is customized according to your specific requirements and specifications. For example, you can choose between three different interface options: USB, RS-232 or DB15.

Catalog Gentec

Contact

You have questions?
Contact us

Benefits

Precise measurements at high power: Captures laser measurements up to 1 kW with high accuracy, ideal for demanding applications.
Durability thanks to robust coating: The resistant coating protects the device from damage even during intensive use.
Flexibility thanks to wide spectral range: Covers wavelengths from 0.19 to 2.5 µm and is therefore suitable for various laser sources.
Customizability: Each unit is made to measure to meet the specific requirements of the customer's application.

Features
